SMF SERIES

SMCJ18A

力特SMCJ18A 無鹵素,且符合RoHS標準 適用于表面貼裝應用,可優化電路板空間 小尺寸封裝 內置式應力消除 玻璃鈍化結 低電感 出色的箝位能力 重復頻率(工作循環): 0.05% 快速的響應時間: 從0伏特至VBR最小值通常小于1.0ps 電壓高于10V時,標準IR小于1mA 高溫焊接: 接線端250°C./10秒 塑料封裝已獲UL易燃性分級94V-O認證

Part

Number

(Uni)

Part

Number

(Bi)

Marking

(UNI)

Marking

(BI)

Reverse

Stand off Voltage VR(Volts)

MIN

Breakdown

VoltageVBR

@IT(V)

Max

Breakdown

VoltageVBR

@IT(V)

TestCurrent

IT(mA)

Maximum

Clamping

VoltageVC

@Ipp(V)

Maximum

PeakCurrent

Ipp(A)

Maximum

Reverse

LeakageIR

@VR(μA)

Data Sheet
SMCJ150A SMCJ150CA GHM BHM 150.0 167.00 185.00 1 243.0 6.2 1
SMCJ200A SMCJ200CA GHV BHV 200.0 224.00 247.00 1 324.0 4.6 1
SMCJ440A SMCJ440CA GJM BJM 440.0 492.00 543.00 1 713.0 2.1 1
SMCJ400A SMCJ400CA GJK BJK 400.0 447.00 494.00 1 648.0 2.3 1
SMCJ350A SMCJ350CA GJG BJG 350.0 391.00 432.00 1 567.0 2.6 1
SMCJ300A SMCJ300CA GJE BJE 300.0 335.00 371.00 1 486.0 3.1 1
SMCJ250A SMCJ250CA GHZ BHZ 250.0 279.00 309.00 1 405.0 3.7 1
SMCJ220A SMCJ220CA GHX BHX 220.0 246.00 272.00 1 356.0 4.2 1
SMCJ180A SMCJ180CA GHT BHT 180.0 201.00 222.00 1 292.0 5.1 1
SMCJ170A SMCJ170CA GHR BHR 170.0 189.00 209.00 1 275.0 5.5 1
SMCJ160A SMCJ160CA GHP BHP 160.0 178.00 197.00 1 259.00 5.8 1
SMCJ130A SMCJ130CA GHK BHK 130.0 144.00 159.00 1 209.0 7.2 1
SMCJ120A SMCJ120CA GHG BHG 120.0 133.00 147.00 1 193.0 7.8 1
SMCJ110A SMCJ110CA GHE BHE 110.0 122.00 135.00 1 177.0 8.5 1
SMCJ100A SMCJ100CA GGZ BGZ 100.0 111.00 123.00 1 162.0 9.3 1
SMCJ90A SMCJ90CA GGX BGX 90.0 100.00 111.00 1 146.0 10.3 1
SMCJ85A SMCJ85CA GGV BGV 85.0 94.40 104.00 1 137.0 11.0 1
SMCJ78A SMCJ78CA GGT BGT 78.0 86.70 95.80 1 126.0 11.9 1
SMCJ75A SMCJ75CA GGR BGR 75.0 83.30 92.10 1 121.0 12.4 1
SMCJ70A SMCJ70CA GGP BGP 70.0 77.80 86.00 1 113.0 13.3 1
SMCJ64A SMCJ64CA GGM BGM 64.0 71.10 78.60 1 103.0 14.6 1
SMCJ60A SMCJ60CA GGK BGK 60.0 66.70 73.70 1 96.8 15.5 1
SMCJ58A SMCJ58CA GGG BGG 58.0 64.40 71.20 1 93.6 16.1 1
SMCJ54A SMCJ54CA GGE BGE 54.0 60.00 66.30 1 87.1 17.3 1
SMCJ51A SMCJ51CA GFZ BFZ 51.0 56.70 62.70 1 82.4 18.2 1
SMCJ48A SMCJ48CA GFX BFX 48.0 53.30 58.90 1 77.4 19.4 1
SMCJ45A SMCJ45CA GFV BFV 45.0 50.00 55.30 1 72.7 20.6 1
SMCJ43A SMCJ43CA GFT BFT 43.0 47.80 52.80 1 69.4 21.7 1
SMCJ40A SMCJ40CA GFR BFR 40.0 44.40 49.10 1 64.5 23.3 1
SMCJ36A SMCJ36CA GFP BFP 36.0 40.00 44.20 1 58.1 25.9 1
SMCJ33A SMCJ33CA GFM BFM 33.0 36.70 40.60 1 53.3 28.2 1
SMCJ30A SMCJ30CA GFK BFK 30.0 33.30 36.80 1 48.4 31.0 1
SMCJ28A SMCJ28CA GFG BFG 28.0 31.10 34.40 1 45.4 33.1 1
SMCJ24A SMCJ24CA GEZ BEZ 24.0 26.70 29.50 1 38.9 38.6 1
SMCJ26A SMCJ26CA GFE BFE 26.0 28.90 31.90 1 42.1 35.7 1
SMCJ22A SMCJ22CA GEX BEX 22.0 24.40 26.90 1 35.5 42.3 1
SMCJ20A SMCJ20A GEV BEV 20.0 22.20 24.50 1 32.4 46.3 1
SMCJ18A SMCJ18CA GET BET 18.0 20.00 22.10 1 29.2 51.4 1
SMCJ17A SMCJ17A GER BER 17.0 18.90 20.90 1 27.6 54.4 1
SMCJ16A SMCJ16A GEP BEP 16.0 17.80 19.70 1 26.0 57.7 1
SMCJ15A SMCJ15A GEM NEM 15.0 16.70 18.50 1 24.4 61.5 1
SMCJ14A SMCJ14CA GEK BEK 14.0 15.60 17.20 1 23.2 64.7 1
SMCJ13A SMCJ13CA GEG BEG 13.0 14.40 15.90 1 21.5 69.8 1
SMCJ12A SMCJ12A GEE BEE 12.0 13.30 14.70 1 19.9 75.4 1
SMCJ11A SMCJ11A GDZ BDZ 11.0 12.20 13.50 1 18.2 82.5 1
SMCJ10A SMCJ10CA GDX BDX 10.0 11.10 12.30 1 17.0 88.3 5
SMCJ9.0A SMCJ9.0CA GDV BDV 9.0 10.00 11.10 1 15.4 97.4 10
SMCJ8.5A SMCJ8.5CA GDT BDT 8.5 9.44 10.40 1 14.4 104.2 20
SMCJ8.0A SMCJ8.0CA GDR BDR 8.0 8.89 9.83 1 13.6 110.3 50
SMCJ7.5A SMCJ7.5CA GDP BDP 7.5 8.33 9.21 1 12.9 116.3 100
SMCJ7.0A SMCJ7.0CA GDM BDM 7.0 7.78 8.60 10 12.0 125.0 200
SMCJ6.5A SMCJ6.5CA GDK BDK 6.5 7.22 7.98 10 11.2 134.0 500
SMCJ6.0A SMCJ6.0CA GDG BDG 6.0 6.67 7.37 10 10.3 145.7 800
SMCJ5.0A SMCJ5.0CA GDE BDE 5.0 6.4 7.00 10 9.2 236.0 800
